.2kw (6HP) driven spindle
• Programmable spindle controls with a maximum 24,000RPM
• Maximum processing width: 610mm (24″)
• Tenon dimensions: See following profile mode specific details
• Workable part dimensions: See following profile mode specific details
• Spindle vertical adjustment: 100mm (4″) servo positioned
• Usable bits: See following detail
• Recommend working pneumatics: 90PSI on a 3/8″ air line
• 200 Programmable profile memory
• Dust port (2) 4″ requiring 436CFM @ point of extraction
• 195in/min dovetail bit acceleration
• Bit sharpening compensation adjustments via touchscreen interface
• Automatic bit recognition
• Horizontal & Vertical pneumatic clamping allows individual part release and mitered profiles
• Easy to understand error detection and display
• Net weight: 1,654lbs
• Gross weight: 1,764lbs
• Machine dimensions: (L) 48″ x (W) 48″ x (H) 43″
• Packing dimensions: (L) 56″ x (W) 56″ x (H) 51″
• (1) Tool box
• Warranty is one year parts
• All machines are tested stateside prior to shipment providing trouble free start up
