Motor: 1 HP, 3450 rpm, 115/230 V, 60 Hz., Single Phase

Spindle: Accepts 7/8-14 RH TPI

Maximum Bit Diameter with Spindles at 3/4″ on Center: 5/8″

Drill Stroke (Carriage Stroke): 3-7/8″

Minimum/Maximum Center Distance of Spindle: 3/4″ to 3″

Air Requirement: 90 PSI

Table Travel to Center Of Bit: 3-1/2″

Maximum Material Thickness (Table to guard): 8-1/2″

Table Size: 15-3/4″x 9-7/8″

Overall Dimensions: Length 37-1/2″, Width 15-3/4″, Height 48″

Weight: 303lbs
